The standard features of the Mercedes-Benz Sprinter 2500 Normal Roof include 3.0L V-6 188HP engine intercooled turbo, 5-speed automatic transmission with overdrive, 4-wheel anti-lock brakes (ABS), automatic air conditioning, 16" steel wheels, ABS and driveline traction control, stability control, power windows, power locks, remote keyless entry, and AM/FM stereo in-dash mounted single CD MP3 decoder, with 5 speakers.

Media Gallery

Click on an image below to enlarge

• Interior Photos
• Exterior Photos
• 360° Photos

•
•
•
•
•
•

•
•
•
•
•
•

• exterior
• interior

Quick Stats

Specifications

• Powertrain
• Entertainment Features
• Seats and Trim
• Warranty
• Suspension/Handling
• Convenience Features
• Specs and Dimensions
• Body Exterior
• Lighting, Visibility and Instrumentation
• Safety and Security

• Engine liters - 3.0
• Compressor - intercooled turbo
• Cylinder configuration - V-6
• Horsepower - 188hp @ 3,800RPM
• Torque - 325 lb.-ft. @ 1,400RPM
• Number of valves - 24
• Engine location - front
• Recommended fuel - diesel
• Transmission - 5 speed automatic
• Manual-shift auto
• Drive type - rear-wheel
• Fuel tank capacity - 26.4gal.

• AM/FM radio
• CD player
• MP3 decoder
• Weather band radio
• Speakers - 5

• Max seating capacity - 2
• Front seats - bucket
• Driver seat mounted armrest
• Passenger seat mounted armrest

• Basic warranty - 36 months/36,000miles
• Powertrain warranty - 36 months/36,000miles
• Corrosion perforation warranty - 60 months/100,000miles
• Roadside assistance coverage - 36 months/36,000miles

• Front wheel independent suspension
• Front anti-roll bar
• Rear anti-roll bar
• Power steering
• Front tires - 245/75QR16.0E
• Rear tires - 245/75QR16.0E
• Single rear wheels
• Wheel size - 16"

• Air conditioning
• Automatic temperature control
• Residual heat recirculation
• Power windows
• 1-touch down
• Remote keyless entry
• Illuminated entry
• Tilt steering wheel
• Telescoping steering wheel
• Front beverage holders
• Overhead console
• Driver door bin
• Passenger door bin

• Engine displacement - 3.0 L
• Engine horsepower - 188hp @ 3,800RPM
• Engine torque - 325 lb.-ft. @ 1,400RPM
• Engine bore x stroke - 83.0mm x 92.0mm (3.27" x 3.62")
• Compression ratio - 18.00 to 1
• Payload - 1,574kg (3,469lbs)
• Curb weight - 2,305kg (5,081lbs)
• GVWR - 3,878kg (8,550lbs)
• Towing capacity - 2,268kg (5,000lbs)
• Exterior length - 5,906mm (232.5")
• Exterior body width - 2,024mm (79.7")
• Exterior height - 2,446mm (96.3")
• Wheelbase - 3,665mm (144.3")
• Turning radius - 7.3m (23.8')7.3 '
• Interior cargo volume - 9,005 L (318 cu.ft.)
• Interior maximum cargo volume - 9,005 L (318 cu.ft.)

• Number of doors - 3
• Bodyside moldings

• Tachometer
• Outside temperature display
• Low tire pressure warning

• 4 wheel disc brakes
• ABS brakes
• Brake assist
• Dual front impact airbags
• Ignition disable
• Electronic stability
• Traction control
